1981 BMW R65
|
Engine |
|
|
|
Motor Type |
Four-stroke two cylinder horizontally opposed "Boxer" engine, air cooled |
|
|
Bore x Stroke |
82 x 61.5 mm (3.22 x 2.42 in) |
|
|
Displacement |
649.6 cc |
|
|
Max Power |
45 hp (33 Kw) at 7,250 rpm. From 1981 50 hp 37 Kw at 7,250 |
|
|
Max Torque |
50 Nm / 36 ft lb at 5,500 rpm. From 1981 model: 52.3 Nm / 38 ft lb at 6500 rpm | |
|
Compression Ratio |
9.2 : 1 |
|
|
Valves Per Cylinder |
2 |
|
|
Valve Control |
OHV, using push rod and rocker arm |
|
|
Carburation System |
2 constant depression carburettors, Bing 64/32/2030 - 64/32/2040 or 64/32/307 - 64/32/308 |
|
|
Engine Lubricating System |
Wet sump |
|
|
Power Transmission |
|
|
|
Clutch |
Dry single plate, with diaphragm spring |
|
|
Number of Gears |
5 |
|
|
Gear Selection |
Dog type gearbox (ratchet foot lever) |
|
|
Gearbox Ratios |
4.4 / 2.86 / 2.07 / 1.67 / 1.50 : 1 |
|
|
Rear Wheel Ratio |
1: 3.44 |
|
|
Bevel/Crownwheel |
9 / 31 teeth |
|
|
Electrical System |
|
|
|
Ignition System |
Battery ignition. From 1981 model: Contact free electronic ignition |
|
|
Alternator |
Bosch 280 W |
|
|
Starter |
Bosch 0.7 hp |
|
|
Spark Plugs |
Bosch W 5 D / Beru 14-5D / Champion N 6 Y |
|
|
Chassis |
|
|
|
Type of Frame |
Double loop tubular frame with bolt on rear section |
|
|
Front wheel suspension |
Telescopic fork with hydraulic shock absorber |
|
|
Rear wheel suspension |
Long swinging arm with adjustable strut |
|
|
Spring Travel Front/Rear |
175 / 110 mm (6.88 / 4.33 in) |
|
|
Wheel Rims, Front |
1.85 B 18 |
|
|
Wheel Rims, Rear |
2.50 B 18 |
|
|
Tyres, Front |
3.25 S 18 |
|
|
Tyres, Rear |
4.00 S 18 |
|
|
Brakes, Front |
Single disc brake 260 mm / 10.23 in diameter. Twin disc on later models. ATE 2 piston caliper to 1979. 1979 on models Brembo 2 piston caliper |
|
|
Brakes, Rear |
Simplex drum brake 200 mm / 7.87 in diameter |
|
|
Dimensions/Weights |
|
|
|
Length x Width x Height |
2110 x 688 x 1090 mm (83.07 x 27.08 x 42.91 in) |
|
|
Wheel Base |
1390 mm / 54.72 in to 1980. 1400 mm / 55.11 in |
|
|
Fuel Tank Capacity |
22 litres / 4.83 gal / 5.81 gal US |
|
|
Unladen Weight with Full Tank |
205 Kg / 451 lb |
|
|
Max. Permissible Weight |
398 Kg / 876 lb |
|
|
Ground Clearance |
130 mm / 5.11 in |
|
|
Seat Height (Unladen) Up to 1980 |
770 mm (30.3 inches) |
|
|
Seat Height (Unladen) 1981 On |
810 mm (31.9 inches) |
|
|
Fuel Consumption |
4.6 litres 100 Km (at constant 90 Kph) / 61 mpg / 51 mpg US |
|
|
Top Speed |
175 Kph / 108 mph |
|
|
Acceleration 0 - 100 Kph / 62 mph |
5.9 seconds (1981 model on: 5.8 seconds) |
|
